Methodology
Our team executes SPTs in strict accordance with ASTM D1586 and BS EN ISO 22476-3. The test involves driving a standard split-spoon sampler 450 mm into the soil using a 63.5 kg hammer falling 760 mm, recording blow counts (N-value) for each 150 mm interval. In London, we typically conduct SPTs at 1.0 to 1.5 m intervals to capture variations in London Clay and gravel layers. Corrections for overburden pressure, rod length, and energy efficiency are applied to derive N60 values. This data is integrated with cone penetration test (cpt) results and laboratory testing for comprehensive geotechnical profiles.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Predominant soil type | London Clay (high plasticity), River Terrace Gravels, Chalk |
| Maximum seismic acceleration (PGA) (return period 475 years) | 0.10g – 0.15g (UK National Annex to Eurocode 8) |
| Typical groundwater level | 2 – 8 m below ground surface (variable with season and location) |
| Bedrock depth | Chalk at 50 – 150 m depth (underlying London Clay) |
| Typical N60 range (London Clay) | 15 – 40 blows/300 mm (increase with depth) |
Local Considerations — London
London's geology is dominated by the London Clay Formation, a stiff overconsolidated clay that provides good bearing capacity but poses challenges for deep excavations due to swelling and shrinkage. Groundwater levels are generally high, often encountered within 2–5 m in the River Terrace Gravels, requiring careful dewatering and SPT corrections. Seismic hazard is low to moderate (PGA up to 0.15g per Eurocode 8), but liquefaction assessment is needed in loose granular fills near the Thames. Contrast exists between the clay-rich central areas and gravels in the Thames Valley. Our team addresses these conditions by integrating dpsh dynamic probing for shallow gravel layers and SPT for deeper clay profiles, ensuring reliable design parameters.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at contact@standardpenetrationtest.net
Services in London
Locations covered in London
Applicable Standards
- BS 5930 (Code of practice for ground investigations)
- Eurocode 7 (EN 1997-1 and EN 1997-2)
- ASTM D1586 (Standard Test Method for Standard Penetration Test)
- BS EN ISO 22476-3 (Geotechnical investigation and testing – Field testing – Part 3: Standard penetration test)
- Eurocode 8 (EN 1998-5: Seismic design of foundations)
Frequently Asked Questions
What soil conditions are typical for SPT in London?
London's subsurface primarily consists of fill, River Terrace Gravels, London Clay, and Chalk. SPTs are effective in all these materials, with N-values ranging from low in fills to high in dense gravels and stiff clay. The London Clay typically yields N60 values of 20–40 blows/300 mm.
Is seismic design required for foundations in London?
Yes, according to Eurocode 8 and the UK National Annex, seismic design is required for structures in seismic class II or higher. London falls in low to moderate seismicity zones (PGA up to 0.15g). SPT data is essential for liquefaction assessment and site classification.
Are SPTs mandatory for building projects in London?
While not mandatory by law, SPTs are standard practice for most medium to large projects to comply with Eurocode 7 and Building Regulations. Local authorities often require ground investigation reports, and SPT provides critical design parameters for foundations and retaining walls.
