Methodology
Our DPL procedure follows BS EN ISO 22476-2:2005, using a 10 kg hammer dropped from 0.5 m to drive a 50 mm diameter cone at a constant rate. The number of blows per 0.1 m penetration (Nd10) is recorded to derive soil resistance. We typically achieve depths of 5–8 m in granular soils, with continuous data logging at 0.1 m intervals. For cohesive soils, we reduce penetration rate to avoid disturbance. All equipment is calibrated annually to maintain accuracy within ±5%. Complementary techniques such as Cone Penetration Test (CPT) are used for deeper profiling when required.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Hammer Mass | 10 kg |
| Drop Height | 0.5 m |
| Cone Diameter | 50 mm |
| Blow Count (Nd10) | 1–50 blows/0.1 m |
| Maximum Depth | 8 m (typical in granular soils) |
Local Considerations — United Kingdom
The United Kingdom's diverse geology—from London Clay to glacial tills in Aberdeen and chalk in Ashford—requires adaptable probing strategies. In Aylesbury, high groundwater tables necessitate careful logging, while Barnsley's former mining areas demand deeper penetration to bypass fill. Our team adjusts hammer energy and penetration rates to suit local conditions, ensuring reliable data across all regions. We maintain a national fleet of DPL rigs stationed in key hubs, enabling rapid mobilisation to any site within 48 hours.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at contact@standardpenetrationtest.net
Applicable Standards
- BS EN ISO 22476-2:2005
- BS 5930:2015 (Code of practice for ground investigations)
- Eurocode 7 (EN 1997-2:2007)
Frequently Asked Questions
What is the typical depth range for DPL Light Dynamic Probing?
Our DPL service typically achieves depths of 5 to 8 metres in granular soils, though maximum depth depends on ground resistance and groundwater conditions. For cohesive or very dense strata, depth may reduce to 3–5 metres. We always assess site conditions beforehand to confirm feasibility.
How does DPL differ from Standard Penetration Test (SPT)?
DPL uses a lighter hammer (10 kg vs 63.5 kg) and smaller cone (50 mm vs 50 mm split spoon), providing continuous resistance profiles at shallower depths. SPT offers discrete samples and is preferred for deeper boreholes. DPL is faster and more cost-effective for preliminary surveys, while SPT complements it for detailed design.
What standards govern DPL testing in the UK?
DPL testing in the UK is conducted in accordance with BS EN ISO 22476-2:2005, which specifies equipment, procedure, and reporting. We also adhere to BS 5930:2015 for overall ground investigation and Eurocode 7 (EN 1997-2) for geotechnical design. All our reports include blow count records and interpreted soil profiles.
How much does DPL Light Dynamic Probing cost in the United Kingdom?
Costs vary based on depth, accessibility, and number of test points. A typical single DPL test to 5 m depth ranges from £250 to £500, with discounts for multiple points. For an accurate quote, please contact our team with site details—we provide free feasibility assessments and cost estimates within 24 hours.
