Methodology
Our standard penetration test (SPT) methodology follows ASTM D1586 and BS EN ISO 22476-3. We deploy a 63.5 kg drop hammer with automatic trip release to drive a split-spoon sampler 450 mm, recording blow counts per 150 mm increment. In Barnsley, we typically perform SPT at 1.5 m intervals to 15–25 m depth, depending on bedrock depth. Our team uses calibrated equipment and real-time data logging to ensure repeatability. For soft ground, we supplement with cone penetration test (CPT) profiles. All results are corrected for energy ratio (ERi) and overburden pressure to yield N60 values for design.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Predominant soil type | Glacial till (boulder clay) over Coal Measures mudstone/sandstone |
| Typical N60 range (0–10 m) | 8–25 blows/300 mm |
| Maximum seismic acceleration (PGA) | 0.05g–0.08g (Eurocode 8 Zone 1) |
| Typical groundwater level | 2–6 m below ground surface (shallow in valleys) |
| Bedrock depth | 10–30 m (variable due to glacial drift and mining) |
Local Considerations — Barnsley
Barnsley lies on Carboniferous Coal Measures with extensive glacial till cover. Historical mining creates voids and variable ground conditions, requiring careful SPT interpretation. The Dearne Valley has deep alluvium with potential liquefaction under seismic loading. In contrast, higher ground on the Pennine foothills offers stiffer tills. Our team integrates SPT data with mining records and desk studies. For regional context, we also offer standard penetration test en Leeds for projects across Yorkshire. A typical challenge is backfilled colliery spoil, where SPT blow counts can be misleading; we combine SPT with cone penetration test (cpt) to refine stratigraphy.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at [email protected]
Services in Barnsley
Applicable Standards
- ASTM D1586
- BS EN ISO 22476-3
- Eurocode 7 (BS EN 1997-2)
- Eurocode 8 (BS EN 1998-5)
- BS 5930:2015
Frequently Asked Questions
What soil types are encountered in Barnsley during SPT?
The predominant soils are glacial till (boulder clay) overlying Coal Measures mudstone, sandstone, and shale. In valleys, alluvial silts and clays are present. SPT blow counts in till typically range from 8 to 25, while coal measures can exceed 50. Mining spoil and backfill require cautious interpretation.
Is seismic design required for projects in Barnsley?
Yes, per Eurocode 8, Barnsley falls in Zone 1 with a PGA of 0.05g–0.08g. While low seismicity, liquefaction assessment is still needed for saturated loose sands in the Dearne Valley. SPT N60 values are used in simplified liquefaction evaluation procedures.
Are geotechnical investigations mandatory for building in Barnsley?
While not explicitly mandatory for all projects, UK building regulations require foundation design to be based on adequate ground investigation. Local planning authorities often require a geotechnical report for developments on brownfield or mining-affected land. SPT is a key component of such investigations.
